| MOQ: | 3000 sets |
| Price: | $30,000.00 - $40,000.00/sets |
| Name:ShangHai Long shou Machinery Co,Ltd |
| Sany Heavy Industry SY365H (National IV) Excavator Parameter Configuration |
| specifications |
| Power Traditional Power |
| Domestic production by manufacturers |
| Bucket Backhoe |
| Tonnage (ton) 37 |
| Working weight of the whole machine (kg) 36800 |
| Bucket capacity (m ³) one point nine |
| performance |
| Rotation speed (rpm) 9.2 |
| Walking speed (km/h) 5.5/3.5 |
| Climbing ability (%) 35 ° |
| Ground specific voltage (Kpa) 67 |
| Bucket excavation force (kN) 235 |
| Dipper arm excavation force (kN) 210 |
| dynamic system |
| Engine model Isuzu 6HK1 |
| Rated power (kW/rpm) 210/1900 |
| Maximum torque (N.m) 1080/1500 |
| Displacement (L) 7.79 |
| Emission Standard National IV |
| Oil capacity |
| Fuel tank (L) 620 |
| Engine oil change quantity (L) 41 |
| Main body size |
| Track shoe width (mm) 600 |
| Number of carrier sprockets (one side) (2 pieces) |
| Number of track shoes (one side) (pieces) 49 |
| Number of supporting wheels (one side) 9 |
load method
advantage and weekness :best ,keep machine complete and well .u can use when received it ,only waste freight
Method 2 (take boom and bucket out ,put boom on top of machine or other pieces ,same CBM )
Method 3 use 40FR Frame
Method 4 use 40HQ container ,cheapest but destroy machine
|
|
