| MOQ: | 3000 sets |
| Price: | $14,000.00 - $20,000.00/sets |
| Company name:Shanghai Longshou Machinery Co,.Ltd. |
| Contact person:Tony |
| Specifications |
|
|
| Working weight of the whole machine (kg) 8850 |
|
|
| Bucket capacity (m) ³) zero point three nine |
|
|
| Origin: Shanghai |
|
|
| Tonnage (ton) 9 |
|
|
| Domestic manufacturers |
|
|
| Power traditional power |
|
|
| Bucket backhoe |
|
|
| Domestic manufacturers |
|
|
| Power traditional power |
|
|
| performance |
|
|
| Slewing speed (RPM) 11.2 |
|
|
| Traveling speed (km / h) 5.0 / 2.9 |
|
|
| Climbing capacity (%) 70% / 35 ° |
|
|
| Grounding specific voltage (kPa) 36 |
|
|
| Bucket digging force (KN): 63.6 |
|
|
| Stick digging force (KN): 46.8 |
|
|
| dynamic system |
|
|
| Engine model Isuzu 4gj1-taba-01-c2 |
|
|
| Rated power (kW / RPM) 53.8/2150 |
|
|
| Maximum torque (N.m / RPM) 255 / 1800 |
|
|
| Displacement (L) 3.059 |
|
|
| Cooling mode: water cooling |
|
|
| Working mode: 4-cylinder, 4-stroke, water cooling, direct injection |
|
|
| Oil capacity |
|
|
| Fuel tank (L) 160 |
|
|
| Hydraulic oil tank (L) 130 |
|
|
| Engine oil change quantity (L) 9 |
|
|
| Body size |
|
|
| Total transport length (mm) 6560 |
|
|
| Total transportation width (mm) 2260 |
|
|
| Total transport height (mm) 2720 |
|
|
| Full height of cab (mm) 2720 |
|
|
| Upper vehicle width (mm) 2160 |
|
|
| Track grounding length (mm) 2340 |
|
|
| Total track length (mm) 2980 |
|
|
| Track shoe width (mm): 450 |
|
|
| Track gauge (mm) 1810 |
|
|
| Minimum ground clearance (mm) 360 |
|
|
| Rear end turning radius (mm) |
|
|
| Scope of work |
|
|
| Maximum excavation radius (mm) 6660 |
|
|
| Maximum excavation depth (mm) 4330 |
|
|
| Maximum excavation height (mm) 7260 |
|
|
| Maximum unloading height (mm) 5210 |
|
|
| Maximum vertical excavation depth (mm) 3080 |
|
|
| Width of bulldozer plate × Height (mm) 420 (height) |
|
|
| Bulldozer lift or push depth (mm) lift 330 / push depth 330 |
load method
advantage and weekness :best ,keep machine complete and well .u can use when received it ,only waste freight
Method 2 (take boom and bucket out ,put boom on top of machine or other pieces ,same CBM )
Method 3 use 40FR Frame
Method 4 use 40HQ container ,cheapest but destroy machine
|
|
