| Brand Name: | komatsu |
| Price: | $29,000.00/sets >=1 sets |
Detailed parameters of Komatsu PC200-8 excavator
Main performance parameters
Classification: Crawler excavator
Brand: Komatsu
Standard bucket capacity: 0.8m ³
Vehicle weight: 19500KG
Engine power: 110KW
Engine brand: Komatsu
Engine model: SAA6D107E-1
Rated engine speed: 2000r/min
Engine fuel tank capacity: 400L
Engine displacement: 6.69L
Maximum excavation height: 10000mm
Maximum unloading height: 7110mm
Maximum excavation depth: 6620mm
Maximum vertical excavation depth: 5980mm
Maximum excavation radius: 9875mm
Minimum turning radius: 3040mm
8 feet horizontal maximum excavation depth: 6370mm
Boom length: 5700mm
Stick length: 2925mm
Dipper arm excavation force (ISO): 108kN
Bucket excavation force (ISO): 149kN
Standard bucket width: 1045mm
Set pressure of rotary oil circuit relief valve: 28.9Mpa
Working oil circuit relief valve set pressure: 37.3Mpa
Setting pressure of the overflow valve for the walking oil circuit: 37.3Mpa
Pilot oil circuit relief valve set pressure: 3.2Mpa
Number of boom cylinders * cylinder diameter * stroke: 2-120 * 1334 * 85mm
Number of stick cylinders * cylinder diameter * stroke: 1-135 * 1490 * 95mm
Bucket cylinder quantity * cylinder diameter * stroke: 1-115 * 1120 * 80mm
Hydraulic oil tank capacity: 135L
Engine coolant capacity: 20.4L
Engine oil capacity: 23.1L
Rotating device capacity: 6.6L
Track shoe width: 600mm
Track length: 4070mm
Number of track shoes/section (per side): 45
Track center distance/track gauge: 2200mm
Track grounding length (wheel spacing): 3275mm
Number of carrier sprockets (per side): 2
Number of supporting wheels (per side): 7
Grounding specific pressure: 45.1kPa
Maximum traction force: 178KN
Driving speed (high/low): 5.5/3.0km/h
Rotation speed: 12.4r/min
Climbing ability: 70%
Tail turning radius: 2750mm
Minimum ground clearance: 440mm
Ground clearance of counterweight: 1085mm
Boarding platform width: 2710mm
Get off platform width: 2800mm
Total height of the cab: 3040mm
Overall length of the machine: 9425mm
Full width of the whole machine: 2800mm
Whole machine height: 2970mm
Excavator Load Method 1 :In bulk or Roroship whole complete machine on boat
Excavator Load Method 2 :In bulk or Roroship.take boom and bucket out
Excavator Load Method 3 :40FR load
Excavator Load Method 4 :40HQ Container
|
|
