| Price: | $50,000.00/sets >=1 sets |
Excavator parameters
Working weight of the whole machine (kg) 36900
Bucket capacity (m ³) 1.35-3.0
Boom length (mm) 6450
Stick length (mm) 3200
performance
Rotation speed (rpm) 9.7
Walking speed (km/h) 3.3/4.5
Climbing ability (%) 70
Ground specific voltage (Kpa) 65.9
Bucket excavation force (kN) 215.0 (standard mode)/236.0 (force application mode)
Bucket digging force (kN) 161.0 (standard mode)/176.0 (force application mode)
dynamic system
Engine model Volvo D12D
Rated power (kW/rpm) 198/1700
Maximum torque (N.m) 1475/1275
Displacement (L) 12.1
Number of cylinders (6)
Cylinder diameter x stroke (mm) 131 x 150
Cooling method: water cooling
Working form: turbocharging
hydraulic system
Main pump type variable axial piston pump × 2+variable pump
Walking hydraulic motor type variable axial piston motor
Rotary hydraulic motor type axial piston hydraulic motor
Maximum flow rate of main pump (l/min) 280 × 2+25.5
Working hydraulic oil circuit (Mpa) 31.4/34.3
Hydraulic circuit for walking (Mpa) 34.3
Rotary hydraulic circuit (Mpa) 25.5
Control hydraulic circuit (Mpa) 3.9
Boom oil cylinder - number x cylinder diameter x stroke (mm) 2-160 x 1530
Stick oil cylinder - number x cylinder diameter x stroke (mm) 1-175 x 1700
Bucket oil cylinder - number x cylinder diameter x stroke (mm) 1-145 x 1285
Oil capacity
Fuel tank (L) 620
Hydraulic oil tank (L) 220
Hydraulic system (L) 500
Engine oil change quantity (L) 42
Cooling liquid (L) 60
Main body size
Total length of transportation (mm) 11070
Total transportation width (mm) 3340
Total transportation height (mm) 3350
Full height of cab (mm) 3190
Track grounding length (mm) 4240
Total length of track (mm) 5180
Track shoe width (mm) 600
Total width of track (mm) 3340
Track gauge (mm) 2740
Minimum ground clearance (mm) 500
Ground clearance of counterweight (mm) 1210
Minimum turning radius of the front working device (mm) 4340
Rear end turning radius (mm) 3390
Scope of work
Maximum excavation radius (mm) 11180
Maximum excavation radius of the parking surface (mm) 10970
Maximum excavation depth (mm) 7490
Maximum excavation height (mm) 10320
Maximum unloading height (mm) 7240
Maximum vertical excavation depth (mm) 5510
Maximum effective excavation depth (mm) 7320
Wheel Loaders Load Method 1:in bulk whole complete
Wheel Loaders Load Method 2:40HQ
|
|
