| MOQ: | 300 sets |
| Price: | $26,000.00 - $33,000.00/sets |
| specifications |
| Power Traditional Power |
| Manufacturer joint venture/import |
| Bucket Backhoe |
| Tonnage (ton) 22 |
| Working weight of the whole machine (kg) 21500 |
| Bucket capacity (m ³) 0.5-1.28 |
| Boom length (mm) 5700 |
| Stick length (mm) 2900 |
| performance |
| Rotation speed (rpm) 12.4 |
| Walking speed (km/h) 3.1-4.5 |
| Bucket excavation force (kN) 136.2/144.1 |
| Dipper arm excavation force (kN) 97/102.9 |
| dynamic system |
| Engine model: Doosan DB58TIS |
| Rated power (kW/rpm) 110/1950 |
| Displacement (L) 6.3 |
| Cooling method: air cooling |
| hydraulic system |
| Main pump type variable axial piston pump |
| Maximum flow rate of main pump (l/min) 2 × 215 |
| Main body size |
| Total length of transportation (mm) 9510 |
| Total transportation width (mm) 2990 |
| Total transportation height (mm) 3030 |
| Full height of cab (mm) 3000 |
| Track grounding length (mm) 3645 |
| Total length of track (mm) 4440 |
| Track shoe width (mm) 600 |
| Total width of track (mm) 2990 |
| Track gauge (mm) 2390 |
| Minimum ground clearance (mm) 480 |
| Ground clearance of counterweight (mm) 1105 |
| Rear end turning radius (mm) 2750 |
| Scope of work |
| Maximum excavation radius (mm) 9910 |
| Maximum excavation radius of the parking surface (mm) 9735 |
|
|
