| Price: | $10,000.00 - $14,000.00/sets |
| Komatsu PC15R-8 excavator |
| specifications |
| Working weight of the whole machine (kg) 1650 |
| Bucket capacity (m ³) 0.04/0.02 |
| Tonnage (ton) 1 |
| Manufacturer joint venture/import |
| Power Traditional Power |
| Bucket Backhoe |
| Manufacturer joint venture/import |
| Power Traditional Power |
| performance |
| Ground specific voltage (Kpa) 29.6 |
| Walking speed (km/h) 4.2 |
| dynamic system |
| Engine model Komatsu 3D68E-N3FB |
| Rated power (kW/rpm) 12.7/2600 |
| Displacement (L) 0.78 |
| Oil capacity |
| Fuel tank (L) 20 |
| Hydraulic system (L) 23 |
| Engine oil change quantity (L) 2.8 |
| Cooling liquid (L) 3.2 |
| Main body size |
| Total length of transportation (mm) 3745 |
| Total transportation width (mm) 1000 |
| Total transportation height (mm) 2229 |
| Full height of cab (mm) 2229 |
| Ground clearance of counterweight (mm) 437 |
| Track grounding length (mm) 1015 |
| Track shoe width (mm) 230 |
| Track gauge (mm) 770 |
| Rear end turning radius (mm) 1070 |
| Scope of work |
| Maximum excavation radius of the parking surface (mm) 3640 |
| Maximum excavation depth (mm) 2160 |
| Maximum excavation height (mm) 3480 |
| Maximum unloading height (mm) 2500 |
| Maximum vertical excavation depth (mm) 1560 |
load method
advantage and weekness :best ,keep machine complete and well .u can use when received it ,only waste freight
Method 2 (take boom and bucket out ,put boom on top of machine or other pieces ,same CBM )
Method 3 use 40FR Frame
Method 4 use 40HQ container ,cheapest but destroy machine
|
|
