| Price: | $18,000.00 - $22,000.00/sets |
|
|
| Specifications |
| Tonnage (ton) 20 |
| Working weight of the whole machine (kg) 20253 |
| Bucket capacity (m ³) zero point eight |
| Stick length (mm) 1840/2410 |
| Origin Japan |
| Power Traditional Power |
| Manufacturer joint venture/import |
| Bucket Backhoe |
| dynamic system |
| Engine model Komatsu SAA6D102E-2 |
| Rated power (kW/rpm) 107 |
| Cooling method: water cooling |
| Cylinder diameter x stroke (mm) 102 x 120 |
| Displacement (L) 5.883 |
| Working mode: 4-stroke, water-cooled, direct injection |
| performance |
| Bucket excavation force (kN) 149 |
| Dipper arm excavation force (kN) 145 |
| Walking speed (km/h) 12.4 |
| hydraulic system |
| Maximum flow rate of main pump (l/min) 2 * 214 |
| Hydraulic circuit for walking (Mpa) 37.3 |
| Rotary hydraulic circuit (Mpa) 28.9 |
| Control hydraulic circuit (Mpa) 3.2 |
| Main pump type variable piston pump |
| Oil capacity |
| Fuel tank (L) 400 |
| Hydraulic oil tank (L) 143 |
| Engine oil change quantity (L) 24 |
| Cooling liquid (L) 22.4 |
| Main body size |
| Total length of transportation (mm) 9480 |
| Total transportation width (mm) 3000 |
| Total transportation height (mm) 2985 |
| Full height of cab (mm) 2095 |
| Rear end turning radius (mm) 3270 |
| Total length of track (mm) 4080 |
| Track shoe width (mm) 600 |
| Total width of track (mm) 3000 |
| Track grounding length (mm) 3270 |
| Scope of work |
| Maximum excavation radius (mm) 9380 |
| Maximum excavation depth (mm) 5380 |
| Maximum excavation height (mm) 9800 |
| Maximum unloading height (mm) 6890 |
| Maximum excavation radius of the parking surface (mm) 8660 |
load method
advantage and weekness :best ,keep machine complete and well .u can use when received it ,only waste freight
Method 2 (take boom and bucket out ,put boom on top of machine or other pieces ,same CBM )
Method 3 use 40FR Frame
Method 4 use 40HQ container ,cheapest but destroy machine
|
|
