| Price: | $23,000.00 - $26,000.00/sets |
|
| Parameter Configuration of Hitachi ZX130-5G Excavator |
| specifications |
| Working weight of the whole machine (kg) 12500 |
| Bucket capacity (m ³) zero point five two |
| Stick length (mm) 2520 |
| Tonnage (ton) 13 |
| Manufacturer joint venture/import |
| Power Traditional Power |
| Bucket Backhoe |
| Manufacturer joint venture/import |
| Power Traditional Power |
| performance |
| Rotation speed (rpm) 13.3 |
| Walking speed (km/h) 5.5/3.3 |
| Climbing ability (%) 70 |
| Ground specific voltage (Kpa) 39 |
| Bucket excavation force (kN) 104 |
| Dipper arm excavation force (kN) 69 |
| dynamic system |
| Engine model Isuzu GJ-4JJ1XKSA-03 |
| Rated power (kW/rpm) 69/2000 |
| Maximum torque (N.m) 354/1600 |
| Displacement (L) 2.999 |
| Number of cylinders 4 |
| Cylinder diameter x stroke (mm) 95 x 105 |
| Working form: 4-stroke, water-cooled, electronically controlled direct injection, turbocharged, intercooled |
| hydraulic system |
| Main pump type: 2 variable axial piston pumps+1 gear pump |
| Rotary hydraulic motor type: 1 inclined plate plunger motor |
| Walking hydraulic motor type: 2 variable swash plate plunger motors |
| Maximum flow rate of main pump (l/min) 2 × 117+33.6 |
| Pilot oil circuit (MPa) 4.0 |
| Working hydraulic oil circuit (Mpa) 34.3 |
| Hydraulic circuit for walking (Mpa) 32.3 |
| Rotary hydraulic circuit (Mpa) 34.3 |
| Boom oil cylinder - number x cylinder diameter x stroke (mm) 2 x 105 x 70 |
| Stick oil cylinder - number x cylinder diameter x stroke (mm) 1 x 115 x 80 |
| Bucket oil cylinder - number x cylinder diameter x stroke (mm) 1 x 100 x 70 |
| Oil capacity |
| Fuel tank (L) 280 |
| Hydraulic oil tank (L) 70 |
| Engine oil change quantity (L) 17 |
| Cooling liquid (L) 24 |
| Main body size |
| Total length of transportation (mm) 7700 |
| Total transportation width (mm) 2490 |
| Total transportation height (mm) 2790 |
| Full height of cab (mm) 2790 |
| Track grounding length (mm) 2880 |
| Total length of track (mm) 3580 |
| Track shoe width (mm) 500 |
| Total width of track (mm) 2490 |
| Track gauge (mm) 1990 |
| Minimum ground clearance (mm) 410 |
| Ground clearance of counterweight (mm) 840 |
| Rear end turning radius (mm) 2190 |
| Scope of work |
| Maximum excavation radius (mm) 8300 |
| Maximum excavation radius of the parking surface (mm) 8170 |
| Maximum excavation depth (mm) 5540 |
| Maximum excavation height (mm) 8600 |
| Maximum unloading height (mm) 6190 |
| Maximum vertical excavation depth (mm) 4750 |
|
|
