| Price: | $26,000.00/sets >=1 sets |
load method
advantage and weekness :best ,keep machine complete and well .u can use when received it ,only waste freight
Method 2 (take boom and bucket out ,put boom on top of machine or other pieces ,same CBM )
Method 3 use 40FR Frame
Method 4 use 40HQ container ,cheapest but destroy machine
| Parameter configuration of Hitachi ZX200 excavator |
| specifications |
| Working weight of the whole machine (kg) 19400 |
| Bucket capacity (m ³) zero point eight |
| Boom length (mm) 5680 |
| Stick length (mm) 2910 |
| Origin Japan |
| Tonnage (ton) 20 |
| Power Traditional Power |
| Bucket Backhoe |
| Manufacturer joint venture/import |
| Power Traditional Power |
| performance |
| Ground specific voltage (Kpa) 43 |
| Rotation speed (rpm) 13.3 |
| Walking speed (km/h) 3.4/5.5 |
| Climbing ability (%) 70/35 ° |
| dynamic system |
| Engine model Isuzu ISUZU AA-6BGIT |
| Rated power (kW/rpm) 109.6/2100 |
| Displacement (L) 6.5 |
| Number of cylinders (6) |
| Working form: intercooling, turbocharging |
| Oil capacity |
| Fuel tank (L) 360 |
| Hydraulic oil tank (L) 200 |
| Engine oil change quantity (L) 25 |
| Cooling liquid (L) 23 |
| Main body size |
| Total length of transportation (mm) 9620 |
| Total transportation width (mm) 2800 |
| Total transportation height (mm) 3130 |
| Full height of cab (mm) 2950 |
| Balance weight ground clearance (mm) 1030 |
| Track grounding length (mm) 3370 |
| Track shoe width (mm) 600 |
| Total width of track (mm) 2800 |
| Track gauge (mm) 2200 |
| Minimum ground clearance (mm) 450 |
| Rear end turning radius (mm) 2750 |
| Scope of work |
| Maximum excavation radius of the parking surface (mm) 9750 |
| Maximum excavation depth (mm) 6670 |
| Maximum excavation height (mm) 9600 |
| Maximum unloading height (mm) 6780 |
| Maximum vertical excavation depth (mm) 6050 |
|
|
