| MOQ: | 2 sets |
| Price: | $38,000.00/sets >=2 sets |
Name:ShangHai Long shou Machinery Co,Ltd
Address: No 1688 South Lian Hua Road, MinHang district.ShangHai, P. R. China
Contact :Olivia
Whats app/Mobile phone:+8618701954897
We chat number:18701954897
specifications
Tonnage (ton) 30
Working weight of the whole machine (kg) 29600
Bucket capacity (m ³) one point two seven
Boom length (mm) 6245/10000
Stick length (mm) 2500/3750/3100/7000
Origin Yantai, China
Power Traditional Power
Manufacturer joint venture/import
Bucket Backhoe
dynamic system
Engine model DE08TIS
Rated power (kW/rpm) 147 (200)/1900
Cylinder diameter x stroke (mm) 111 x 139
Number of cylinders (6)
Displacement (L) 8.07
Working mode: 4-stroke, water-cooled, direct injection
performance
Ground specific voltage (Kpa) 56
Rotation speed (rpm) 10.1
Bucket excavation force (kN) 188/199.9
Dipper arm excavation force (kN) 127.5/135.3
Walking speed (km/h) 5.0/3.1
Rotating torque (Nm) 92
hydraulic system
Main overflow set pressure (Mpa) standard 27.9/Boost 34.3
Maximum flow rate of main pump (l/min) 2 × 246
Hydraulic circuit for walking (Mpa) 32.5
Rotary hydraulic circuit (Mpa) 27.9
Main pump type variable axial column race pump pilot pump flow rate (L/min) 28.5
Oil capacity
Fuel tank (L) 450
Hydraulic oil tank (L) 290
Main body size
Total length of transportation (mm) 10620
Total transportation width (mm) 3200
Total transportation height (mm) 3365 (to the top of the boom)
Full height of cab (mm) 3255
Ground clearance of counterweight (mm) 1175
Minimum ground clearance (mm) 500
Rear end turning radius (mm) 3200
Boarding width (mm) 2960
Total length of track (mm) 4930
Track gauge (mm) 2600
Track shoe width (mm) 600
Total width of track (mm) 3200
Track grounding length (mm) 4010
Scope of work
Maximum excavation radius (mm) 10705
Maximum excavation depth (mm) 7190
Maximum excavation height (mm) 10495
Maximum unloading height (mm) 7470
Maximum vertical excavation depth (mm) 6220
Maximum excavation radius of the parking surface (mm) 9950/11105/10540/17320
Maximum effective excavation depth (mm) 6505/7810/7150/1
|
|
