| Price: | $15,000.00/sets >=1 sets |
Name:ShangHai Long shou Machinery Co,Ltd
Address: No 1688 South Lian Hua Road, MinHang district.ShangHai, P. R. China
Contact :Olivia
Whats app/Mobile phone:+8618701954897
We chat number:18701954897
specifications
Tonnage (ton) 15
Working weight of the whole machine (kg) 13900
Bucket capacity (m ³) 0.28-0.75
Boom length (mm) 4000/4600
Stick length (mm) 1900/2500/3000
Origin Shandong
Power Traditional Power
Manufacturer joint venture/import
Bucket Backhoe
dynamic system
Engine model: Doosan DB58TIS
Rated power (kW/rpm) 71/1850
Cooling method: water cooling
performance
Rotation speed (rpm) 12
Bucket excavation force (kN) standard 77.4/boost 81.3
Dipper arm excavation force (kN) standard 57.8/boost 62 walking speed (km/h) 3.4-4.9
hydraulic system
Rotary hydraulic motor type 26.5 main
Pump maximum flow rate (l/min) 2 × 116
Hydraulic circuit for walking (Mpa) 32.5
Main pump type variable axial column racing pump
Working hydraulic oil circuit (Mpa) standard 32.5/Boost 34.3 Pilot pump flow rate (L/min) 27.7
Main body size
Total length of transportation (mm) 7700
Total transportation width (mm) 2600
Total transportation height (mm) 2830
Full height of cab (mm) 2830
Ground clearance of counterweight (mm) 920
Minimum ground clearance (mm) 410
Rear end turning radius (mm) 2200
Boarding width (mm) 2490
Total length of track (mm) 3495
Track gauge (mm) 2000
Track shoe width (mm) 600
Total width of track (mm) 2600
Track grounding length (mm) 2780
Scope of work
Maximum excavation radius (mm) 7220/8260/8740
Maximum excavation depth (mm) 4670/5630/6130
Maximum excavation height (mm) 7890/8620/8950
Maximum unloading height (mm) 5440/6200/6530
Maximum vertical excavation depth (mm) 4170/5070/5660
Maximum excavation radius of the parking surface (mm) 7050/8110/8600
Maximum effective excavation depth (mm) 4410/5380/5920
|
|
