| MOQ: | 3000 sets |
| Price: | $14,000.00 - $17,000.00/sets |
| Name:ShangHai Long shou Machinery Co,Ltd |
|
|
| Technical parameters of Sany Heavy Industry SY235C-9 excavator |
| Model SY235C-9 |
| Overall size (mm) A Total length (during transportation) 9920 |
| B total width (transportation/operation) 2980 |
| C total height (transportation) 3550 |
| D Upper width 2710 |
| E total height (top of cab) 2990 |
| F standard track shoe width 600 |
| G gauge (transportation/operation) 2380 |
| H minimum ground clearance 440 |
| Tail turning radius 2890 |
| J Track grounding length 3640 |
| K track length 4445 |
| L Track height 965 |
| Scope of work (mm) a Maximum excavation height of 9640 |
| B Maximum unloading height 6725 |
| Maximum excavation depth of 6785 |
| Maximum vertical arm excavation depth of 5845 |
| Maximum excavation distance of 10150 |
| F Minimum turning radius 3800 |
| The maximum height at the minimum turning radius of g is 7940 |
| Performance parameters Total weight kg 24200 |
| Standard bucket capacity m3 1.2 |
| Rated power kW/rpm 128.5/2100 |
| Walking speed (high/low) km/h 5.5/3.5 |
| Rotating speed rpm 11 |
| Climbing ability 70%/35 ° |
| Grounding specific pressure kPa 47.6 |
| Engine model 6BG1-XABEC-03-C2 |
| Bucket excavation force (KN) 175 |
| Dipper arm excavation force (KN) 122 |
| Optional bucket (m3) 1.1~1.2 |
| Optional shoe bandwidth (mm) 800/700 |
| |
|
|
