| Brand Name: | Manniton MT1740 SLT Telescopic Forklift |
| Price: | $50,000.00 - $55,000.00/sets |
load method
advantage and weekness :best ,keep machine complete and well .u can use when received it ,only waste freight
Method 2 (take boom and bucket out ,put boom on top of machine or other pieces ,same CBM )
Method 3 use 40FR Frame
Method 4 use 40HQ container ,cheapest but destroy machine
| Parameter Configuration of Manniton MT1740 SLT Telescopic Forklift |
| Basic performance |
| Engine power (kW) 74.5/2200 |
| Operating weight (kg) 11220 |
| Rated load (kg) 4000 |
| Horsepower (horsepower) above 100 horsepower |
| Maximum load (kg) above 3500 kg |
| Assignment parameters |
| Maximum lifting capacity (kg) 4000 |
| Lifting angle range minimum/maximum (°) -0.028967254 |
| Maximum lifting height (m) 16.65 |
| Maximum external elongation (m) 12.35 |
| Maximum outward extension overturning load (kg) 957 |
| Turning radius (m) 5709 |
| engine |
| Model Perkins 1104D-44T |
| Rated power (kW/rpm) 74.5/2200 |
| Maximum torque (N.m) 412/1400 |
| Displacement (L) 4.4 |
| hydraulic system |
| Maximum working pressure of the system (bar) 260 |
| Maximum system flow rate (L/min) 196 |
| drive system |
| Gear 4 |
| Maximum driving speed (km/h) 25 |
| Tire size 440/80-24 |
| Oil capacity |
| Fuel tank (L) 135 |
| Oil tank (L) 11 |
| Engine coolant (L) 18.5 |
| Transmission oil (L) 16 |
| Hydraulic system (L) 175 |
| External dimensions |
| Overall length of the machine (mm) 7180 |
| Total length of the machine (mm) 5980 |
| Whole machine width (mm) 2425 |
| Whole machine height (mm) 2785 |
| Driver's cab height (mm) 2605 |
| Steering wheel height above ground (mm) 1880 |
| Wheelbase (mm) 2770 |
| Track width (mm) 1990 |
| Ground clearance (mm) 480 |
| Departure angle (°) 50 |
|
|
