| Brand Name: | HOWO 375 |
| Price: | $20,000.00 - $22,000.00/sets |
| Company’s Name:ShangHai Long shou machinery company Limited |
| Address: No 3539A Jingdong Road, MinHang district.ShangHai, P. R. China |
| Contact :Olivia.He |
| Whats app/ Mobile phone:+8618701954897 |
| We chat number:18701954897 |
| E:longshoucompany163.com |
| Vehicle announcement: ZZ3317N4267C1 |
| Brand: China National Heavy Duty Truck Corporation |
| Car series: HOWO |
| Purpose: Dump truck |
| Vehicle type: whole vehicle |
| Drive mode: 8 × 4 |
| Maximum speed: 75km/h |
| Flipping form: rear unloading type |
| Tonnage level: heavy-duty trucks |
| Vehicle reference price: 34-368800 yuan |
| Chassis reference price: 285800 to 288800 yuan |
| Manufacturer: China National Heavy Duty Truck Corporation |
| • Vehicle origin: Jinan, Shandong Province |
| Vehicle parameters |
| Rated mass: 15700kg |
| Curb weight: 15170kg |
| Total weight: 31000kg |
| Vehicle length: 10825mm |
| Vehicle width: 2496mm |
| Vehicle height: 3450mm |
| Container length: 7800mm |
| Box width: 2300mm |
| Container height: 1000mm |
| Front wheelbase: 2022/2022mm |
| Rear wheelbase: 1830/1830mm |
| Front overhang: 1500mm |
| Rear overhang: 1975mm |
| Approach angle: 19 ° |
| • Separation angle: 22 ° |
| Wheelbase: 1800+4200+1350mm |
| Driver's cab |
| • Type of cab: HW76 extended type |
| • Number of passengers allowed: 2 people |
| engine |
| Engine model: China National Heavy Duty Truck WD615.96E |
| Engine form: inline six cylinder, water-cooled, four stroke, turbocharged intercooled, electronically controlled fuel injection rate fuel injection pump, EGR |
| Maximum power: 276KW |
| Maximum power speed: 2200rpm |
| Maximum torque: 1500N. m |
| Maximum torque speed: 1100-1600rpm |
| Maximum horsepower: 375 horsepower |
| Displacement: 9726mL |
| • Fuel type: diesel |
| Emission standards: National III |
| Transmission |
| Transmission model: HW19710 |
| Shift method: manual |
| • Number of forward gears: 10 gears |
| Reverse gear: 2nd gear |
| chassis |
| Chassis model: ZZ3317N4267C1 |
| Number of plate springs: 11/11/12 |
| • Clutch: Φ four hundred and thirty |
| Front axle description: HF9 disc |
| Rear axle description: AC16 |
| tyre |
| Number of tires: 12 |
| Tire specifications: 12 (11) |
|
|
|
|
|
|
The blooming flowers on the construction site light up the entire projet ,colorful ,you can coose any color which u like ,including Gradient color ,army green .rainbow of seven colors etc.
|
|
