| Price: | $25,500.00/sets >=1 sets |
Company’s Name:ShangHai Long shou machinery company Limited
Address: No 3539A Jingdong Road, MinHang district.ShangHai, P. R. China
Contact :Olivia.He
Whats app/ Mobile phone:+8618701954897
We chat number:18701954897
Parameter Configuration of Komatsu PC220-8 Excavator
specifications
Power Traditional Power
Manufacturer joint venture/import
Bucket Backhoe
Working weight of the whole machine (kg) 23100
Bucket capacity (m ³) one
Boom length (mm) 5850
Stick length (mm) 3045
Tonnage (ton) 22
performance
Rotation speed (rpm) 11.7
Walking speed (km/h) 3.1/4.2/5.5
Climbing ability (%) 70/35 °
Ground specific voltage (Kpa) 50.4
Bucket excavation force (kN) 172
Dipper arm excavation force (kN) 129
dynamic system
Engine model Komatsu SAA6D107E-1
Rated power (kW/rpm) 110/2000
Displacement (L) 6.69
Number of cylinders (6)
Cooling method: water cooling
Working form: 6-cylinder, direct injection, turbocharged, post cooled engine; Meets the 2006 EPA/Tier3 and EUIIIA level standards.
hydraulic system
Rotary hydraulic motor type axial piston motor × 1 (with rotary holding valve)
Traveling hydraulic motor type axial piston motor × 2 (with parking brake)
Maximum flow rate of main pump (l/min) 439
Hydraulic circuit for walking (Mpa) 37.3
Rotary hydraulic circuit (Mpa) 28.9
Control hydraulic circuit (Mpa) 3.2 Pilot oil circuit
Boom oil cylinder - number x cylinder diameter x stroke (mm) 130 x 1335 x 90
Stick oil cylinder - number x cylinder diameter x stroke (mm) 140 x 1635 x 100
Bucket oil cylinder - number x cylinder diameter x stroke (mm) 130 x 1020 x 90
Is the hydraulic crushing pipeline standard? No
Oil capacity
Fuel tank (L) 400
Hydraulic oil tank (L) 135
Engine oil change quantity (L) 23.1
Cooling liquid (L) 19.8
Main body size
Total length of transportation (mm) 9885
Total transportation width (mm) 5190
Total transportation height (mm) 3185
Full height of cab (mm) 3055
Track grounding length (mm) 3460
Total length of track (mm) 4260
Track shoe width (mm) 600
Total width of track (mm) 2980
Track gauge (mm) 2380
Minimum ground clearance (mm) 440
Balance weight ground clearance (mm) 1100
Rear end turning radius (mm) 2905
Scope of work
Maximum excavation radius (mm) 10180
Maximum excavation radius of the parking surface (mm) 10020
Maximum excavation depth (mm) 6920
Maximum excavation height (mm) 10000
Maximum unloading height (mm) 7035
Maximum vertical excavation depth (mm) 6010
load method
advantage and weekness :best ,keep machine complete and well .u can use when received it ,only waste freight
Method 2 (take boom and bucket out ,put boom on top of machine or other pieces ,same CBM )
Method 3 use 40FR Frame
Method 4 use 40HQ container ,cheapest but destroy machine
|
|
